XQ Servos

Description:
The XQ 4013 servo is the best option out there for 30cc sized 3d planes. Perfect combination of speed and torque and a price point that make the other servo companies jealous.

The XQ 4013 has superior reliability to other servos. They have a core less digital motor, for precise strong movement. The XQ 4013 has all titanium gears, heat sink to reduce overheating, waterproof housing, and great torque and speed.

The XQ 4013 is perfect for a 30CC 3D plane for ALL surfaces. They can be used reliably in a 50cc plane also on all surfaces.

Specifications:

• Torque:
  • 166.7 oz/in at 4.8V (12.0 kg/cm)
  • 197.2 oz/in at 6V (12.8 kg/cm)

• Speed:
  • .13 sec at 4.8V
  • .11 sec at 6V

• Voltage: 4.8V - 6V
• Weight: 2 oz (59g)
• Size: 40x20x39mm

• Gear Style: Futaba Arms
• Modulation: Coreless Digital
• Gear Type: Titanium
• Weight: 2oz (59g)
• Size: 40x20x39mm

Watch this video of the XQ 4013 beating the Hitec 7985mg

Features:

• Titanium Gears
• Waterproof
• Coreless
• Digital
• High Torque/High Speed
• Smooth resolution

Don't forget to buy some circle servo arms to fit your carbon fiber arms you got in your kit!



Description:
XQ-3011 Metal gear analog servo

Specifications:

• Torque:
  • 152 oz/in at 6V (11 kg/cm)
  • 172 oz/in at 7.2V (12.4kg-cm)


• Speed:
  • .18 sec at 6V
  • .16 sec at 7.2V


• Voltage: 6V - 7.2V

• Weight:1.46oz (56g)

• Size: 40 x 20 x 38mm


• Gear Style: Futaba Arms
• Gear Type: Metal

• Torque:
  • 198.6 oz/in at 9.6V (14.3kg/cm)
  • 238.9 oz/in at 11.1V (17.2kg-cm)


• Speed:
  • .11 sec at 9.6V
  • .11 sec at 11.1V


• Voltage: 9.6V - 11.1V

• Weight: 1.46oz (56g)
• Size: 40 x 20 x 39mm


• Gear Style: Futaba Arms
• Gear Type: Metal - Titanium

Description:
XQ-4220 Metal gear Digital Coreless servo

Specifications:

• Torque:
  • 243 oz/in at 9.6V (17.5kg/cm)
  • 286 oz/in at 11.1V (20.6kg/cm)

• Speed:
  • .13 sec at 9.6V
  • .11 sec at 11.1V

• Voltage: 9.6 - 11.1V
• Weight: 1.46oz (56g)
• Size: 40x20x39mm

• Gear Style: Futaba Arms
• Gear Type: Metal - Titanium

Don't forget to buy some circle servo arms to fit your carbon fiber arms you got in your kit!

• Torque:
  • 340.3 oz/in at 9.6V (24.5kg/cm)
  • 427.7 oz/in at 11.1V (30.8kg/cm)


• Speed:
  • .15 sec at 9.6V
  • .13 sec sec at 11.1V


• Voltage: 9.6V - 11.1V

• Weight: 1.46oz (56g)

• Size:40 x 20 x 39mm


• Gear Style: Futaba Arms
• Gear Type: Metal - Titanium

Description:
XQ-5040 Metal gear Digital servo

Specifications:

• Torque:
  • 465 oz/in at 6V (33.5kg/cm)
  • 550 oz/in at 7.2V (39.8kg/cm)


• Speed:

  • .20 sec at 6V
  • .18 sec at 7.2V


• Voltage: 6V to 7.2V

• Weight: 6.26 oz (177.5 g)

• Size: 2.4 x 1.2 x 2.3 (60x30x59mm)



• Gear Style: Futaba Arms
• Gear Type: Metal



  Don't forget to buy some circle servo arms to fit your carbon fiber arms you got in your kit!


Description:
XQ-4320 Metal gear Digital servo

Specifications:

• Torque:
  • 238 oz/in at 4.8V (17.2 kg/cm)
  • 277 oz/in at 6V (20 kg/cm)


• Speed:
  • .13 sec at 4.8V
  • .11 sec at 6V


• Voltage: 4.8V - 6V

• Weight: 2.57oz (73g)

• Size: 40 x 20 x 39mm


• Gear Style: Futaba Arms
• Gear Type: Metal

Description:
XQ-4616 Metal gear Digital servo

Specifications:

• Torque:
  • 197 oz/in at 4.8V (14.2 kg/cm)
  • 229 oz/in at 6V (16.5 kg/cm)


• Speed:
  • .11 sec at 4.8V
  • .08 sec at 6V


• Voltage: 4.8V - 6V

• Weight: 2.57oz (60g)

• Size: 40 x 20 x 39mm


• Gear Type: Titanium
• Waterproof
• Heat resistant
• Brushless motor
