Description:

The Power-HD DSM44 digital servo is a micro servo with digital control electronics for increased performance. Just like the Power-HD DSP33 ,the DSM44 is also very light and ranks as the secont lightest servo at RedwingRC- weighing only slightly over 6g!!! In the DSM44, the output shaft is supported by a ball bearing for decreased friction, and another great feature is that most of the gears are metal for increased durability! The lead is terminated with a Futaba-compatible standard “JR”-style connector. Servo horns and associated hardware are included.

It is important to note that stalling or back-driving this servo can strip its gears.



Specifications:

• Torque:
  16.66 oz/in at 4.8V (1.2 kg/cm)
  22.21 oz/in at 6V (1.6 kg/cm)

• Speed:
  .09 sec at 4.8V
  .07 sec at 6V

• Voltage: 4.8v to 6v
• Weight: .24oz (6.75 g)
• Size: .68 x .87 x 1.06in (22 x 8.7 x 27mm

• Digital
• Lead Length: 160 mm
• Storage Temperature: -20℃~60℃
• Operating Temperature: -10℃~50℃
• Hardware included
• Suitable for F3P/EPP/KT Airplanes
