FW-190 6CH 47" (1200mm) PNP

Ask a question about this product

Printable version

Options

Our Price:

$229.00

Charger Combo

Extra Prop

Quantity (16)

Notify me when back in stock

Details


Availability	16 in stock
Weight	5.00 lbs
SKU	top-002B
Manufacturer	Top R/C Hobby

6 CH TopRC FW-190 6CH 47" (1200mm) Warbird PNP

Overview

The Focke-Wulf FW-190 Wurger (Shrike) was a German Second World War single-seat, single-engine fighter aircraft designed by Kurt Tank in the late 1930s. Powered by a radial engine, the 190 had ample power and was able to lift larger loads than its well-known counterpart, the Messerschmitt Bf 109. The 190 was used by the Luftwaffe in a wide variety of roles, including day fighter, fighter-bomber, ground-attack aircraft also operating to a lesser degree as a night fighter

This model has some great scale detail including camouflage paint, cockpit inner seat and instument panel as well as the joy stick and signal cable and pre-installed operational decals. High crash-resistant EPO foam material with clear cockpit, authentic paint scheme and nose art offer an attractive and scaled model appearance! Super power and thrust weight ration 1:1 allows pilots to fly inverted and perform inside/outside loops, aileron rolls and other aerobatic maneuvers. 6CH flight controls provide added realism with flaps, retractable landing gear and cockpit canopy release. Kit comes as a Plug And Play (PNP) package that includes all electronic parts except transmitter, receiver, battery, and charger.

Specifications:

wingspan: 1200mm/47''
Length: 1020mm/40.16''
Thrust rate: 1:1
Motor: Out runner brushless AT3511 KV750 (included)
ESC: 40A Brushless ESC (included)
Battery: LI-PO 2200mAh 3S 11.1V (not included) (see all RedwingRC batteries/chargers)
Servo: 9gx7 (included)
R/C System: 2.4 GHz 6ch radio (not included) (see all RedwingRC radios/receivers)
Retractable landing gear: 2PCS

Features:

6 channel full function radio controlled (Aileron,Elevator, Rudder, Throttle, Flaps, Gear and Canopy)
High quality, great stability, high performance, and aerobatic capability
Constructed of durable EPO flex foam
Easy to assemble and low maintenance
Steerable rear landing gear
Perfect scale performance
Excellent miniature scale airframe
Perfect for park flying
Suitable for both beginners and experienced pilots

DLE 55RA Engine

+ Free Shipping (Continental US only!) If international customer, please contact us for shipping quote. You will be charged separately for shipping.
+ Free 2 Year warranty

Description:
More power! DLE takes 50cc performance to a new level with the rear exhaust DLE-55RA. Everything about this engine screams performance, from the piston skirt - designed to be lightweight for quick throttle response and tons of power - to the rear exhaust that lets you easily install a tuned pipe in your aircraft. The 55RA provides 100 more rpm than the standard DLE-55. It includes engines standoffs, electronic ignition, spark plug and Pitts style muffler.

To pick out your RedwingRC Props Click here.

Download DLE 55RA Mounting Template
Download DLE 55RA Manual Coming Soon

Specifications:

Displacement: 55.6 cc (3.392 cu in)
Bore: 1.77 in (45 mm)
Stroke: 1.38 X in (35 mm)
Weight: 3.6 lb (1.65 g)
Output: 5.5 hp @ 8,500 rpm
Requires: unleaded gasoline, oil, ignition battery & propeller
Includes: electronic ignition, muffler, spark plug, gasket, bolts, machined aluminum standoffs, throttle arm extension & mounting template
Suggested Propellers: 23x8, 24x8
Ignition Battery: 4.8-6.0V NiCd or NiMH, 6.6V LiFe or 7.4V LiPo pack (LiPo use requires voltage regulator.)
Compression Ratio: 7.6:1
Gas/Oil Mix: Break in with Lawn Boy(or similar non synthetic oil) at 32:1 Ratio per gallon / Use RedLine oil at 50:1 for long term use after break in.
Replacement Spark Plug: NGK CM6 (DLEG55RA10) or equivalent
Weights (Individual): Engine: 47 oz (1,350 g); Exhaust: 3.1 oz (100 g); Ignition: 5.1oz (120 g)
Recommended Propeller: Redwing 23x8, 24X8. 23x8 is a nice mix of 3d and sport. The 24x8 is more 3d

Features:

Two crankshaft bearings-simple design for lighter weight
Aluminum alloy crankcase
Four petal V-type reed valve bottom induction system
Walbro carburetor
Fully automatic electronic ignition
Two year limited warranty
INCLUDES: Engine, spark plug, standoffs, ignition, muffler, instruction manual

DLE-55 RA

$449.99 449.99

SmartDesign V3 "Trouble Free" Tail Wheel Assembly

Description:

This tail wheel assembly is extremely efficient and reliable. With fewer parts, there is less to worry about and the solid construction makes it the go-to choice for pilots at any skill level. The new V2 design incorporates ball bearings for smooth motion, ball-joint to rudder steering connection, wider CF mounting plate, and slightly larger wheels that the v1. "Trouble Free" means just that... no more worrying about screws falling out or loss of control. Make the switch today by installing the SmartDesign Tail Wheel!!!

CNC Aluminum & C.F. Tail Wheel Assembly for 20cc to 220cc

Features:
