Align T-REX 500XT (Torque Tube Drive) TOP Combo With BeastX Plus, Motor, ESC, Servos, & CF Blades

Ask a question about this product

Printable version

Options

Market Price: $938.99

Our Price:

$845.00

You Save

10%

Quantity (1)

Details


Availability	1 in stock
Weight	5.00 lbs
SKU	Heli-RH50E23XT

The Align T-Rex 500X is a refreshing revision of the ever popular 500 class helicopter! Featuring many new updates such as the FL Rotor Head System, larger 470mm main blades, tail rotor belt driven system, & sliding battery tray system. All of the updates both physically and electronically are built to deliver one of the best 500 class flight experiences to date! Typically smaller helicopters are not as stable, and not as powerful as their larger class brothers. The 500X changes this concept drastically and is as stable as it's larger brothers.

Features at a Glance

470mm Main Blades: The larger 470mm main blades aid in providing more stability, power, and performance.
500FL Rotor Head System: Replacing the DFC system, the FL Rotor Head offers excellent stability, a high level of responsiveness, and precision in flight.
Belt Driven Tail System: Improved tail belt system, offering a lower parts count, quick & easy access to belt tension adjustments, and low cost of maintenance.
Align 520MX Brushless Motor: High efficiency, excellent power, high torque, & low current draw.
Align RCE-BL80X ESC: Designed for the 500X and providing current output, with additional support for high voltage BEC output (6V-8.4V).
Align Cyclic & Rudder Servos: Equipped with the DS 530M & DS535M High Voltage Servos, the 500X will benefit from the available high torque and high speed outputs the DS530 & 535HV offer.

TREX 500X test flight

Specifications:
Length: 935mm
Height: 259mm
Main Blade Length: 470mm
Main Rotor Diameter: 1054mm
Tail Rotor Diameter: 219mm
Motor Drive Gear: 12T
Main Drive Gear: 134T
Tail Drive Gear: 21T
Drive Gear Ratio: 11.17:1:3.81
Weight (With Motor): 1400g

Includes:

T-REX 500X Super Combo Kit
(1) Microbeast PLUS Flybarless System
(1) 520MX Brushless Motor (1600KV)
(1) RCE-BL80X Brushless ESC
(1) Set of 470mm Carbon Fiber Blades
(1) Set of 78mm Tail Rotor Blades
(3) DS530M Digital Servos
(1) DS535M Digital Servo

Needed to Complete:

7-channel or more, helicopter transmitter & receiver
6S Li-Po 2600 ~ 3300mAh (3300mAh recommended)
Digital Pitch Gauge

Flat Rate $20 Shipping lower 48 USA only! Contact us at [email protected] for international shipping costs.

XQ 4013 digital 6v

Description:
The XQ 4013 servo is the best option out there for 30cc sized 3d planes. Perfect combination of speed and torque and a price point that make the other servo companies jealous.

The XQ 4013 has superior reliability to other servos. They have a core less digital motor, for precise strong movement. The XQ 4013 has all titanium gears, heat sink to reduce overheating, waterproof housing, and great torque and speed.

The XQ 4013 is perfect for a 30CC 3D plane for ALL surfaces. They can be used reliably in a 50cc plane also on all surfaces.

Specifications:

Torque:
- 166.7 oz/in at 4.8V (12.0 kg/cm)
- 197.2 oz/in at 6V (12.8 kg/cm)
Speed:
- .13 sec at 4.8V
- .11 sec at 6V
Voltage: 4.8V - 6V
Weight: 2 oz (59g)
Size: 40x20x39mm
Gear Style: Futaba Arms
Modulation: Coreless Digital
Gear Type: Titanium
Weight: 2oz (59g)
Size: 40x20x39mm

Watch this video of the XQ 4013 beating the Hitec 7985mg

Features:

Titanium Gears
Waterproof
Coreless
Digital
High Torque/High Speed
Smooth resolution

Don't forget to buy some circle servo arms to fit your carbon fiber arms you got in your kit!

X-4013

$42.50 42.50

DLE 20cc Engine

+ Free Shipping (Continental US only!) If international customer, please contact us for shipping quote. You will be charged separately for shipping.
+ Free 2 Year warranty

Description:
Glow power isn't the only option anymore. The DLE-20 not only fills the displacement gap, but includes a beam mount to make the glow-to-gas upgrade drop-in fast and easy. A rear pumper carb simplifies installation and adjustment of the DLE 20cc. A generous package of "extras" and electronic ignition for starting ease and top performance make the DLE 20 an attractive alternative to glow…and a solid buy for value and performance.

We supply a free 2 year warranty with our DLE 20, and also back it with our in house repair of DLE engines.

Download DLE 20 Manual

Specifications:

Stock Number: DLEG0020
Displacement: 20 cc (1.22 cu in)
Bore: 1.3 in (32 mm)
Stroke: 1.0 in (25 mm)
Weight: 28.9 oz (820 g)
RPM Range: 1,750-9,000
Output: 2.5 hp @ 9,000 rpm
Requires: unleaded gasoline, 2-cycle oil, ignition battery & propeller
Includes: electronic ignition, muffler, spark plug, gasket, bolts, throttle arm extension & manual
Suggested Propellers: 16x8 17x6
Suggested Break-in Prop: 16x8
Ignition Battery: 4.8-6.0V NiCd or NiMH, 6.6V LiFe or 7.4V LiPo pack (LiPo use requires voltage regulator.)
Compression Ratio: 10.5:1
Gas/Oil Mix: Break in with Lawn Boy(or similar non synthetic oil) at 32:1 Ratio per gallon / Use RedLine oil at 50:1 for long term use after break in.
Replacement Spark Plug: NGK CM6 (DLEG5510) or equivalent
Weight Breakdown: Engine: 22.9 oz (650 g); Muffler: 1.8 oz (50 g); Ignition: 4.2 oz (120 g)
Recommended Propeller: Hawk "C" type 17x6 (for 3d), 16x8 (sport/pattern)

DLE-20

$249.99 249.99

SmartDesign V3 "Trouble Free" Tail Wheel Assembly

Description:

This tail wheel assembly is extremely efficient and reliable. With fewer parts, there is less to worry about and the solid construction makes it the go-to choice for pilots at any skill level. The new V2 design incorporates ball bearings for smooth motion, ball-joint to rudder steering connection, wider CF mounting plate, and slightly larger wheels that the v1. "Trouble Free" means just that... no more worrying about screws falling out or loss of control. Make the switch today by installing the SmartDesign Tail Wheel!!!

CNC Aluminum & C.F. Tail Wheel Assembly for 20cc to 220cc

Features:
