BLS-A208+ MINI DIGITAL, HIGH TORQUE, HIGH SPEED, PREMIUM BRUSHLESS SERVO (9.5kg/132.0oz 0.04 sec @8.4V)

Contact UsCustomer Reviews
  0
  5. BLS-A208+ MINI DIGITAL, HIGH TORQUE, HIGH SPEED, PREMIUM BRUSHLESS SERVO (9.5kg/132.0oz 0.04 sec @8.4V)
The Redwing RC Office will be closed 17 Oct-10 Nov. Orders can still be accepted during these times and will be processed in the order received. If you need the item urgently (moved to top of the list), select Priority express and we will do our best to rush the order out to you when we return.
more offers

BLS-A208+ MINI DIGITAL, HIGH TORQUE, HIGH SPEED, PREMIUM BRUSHLESS SERVO (9.5kg/132.0oz 0.04 sec @8.4V)

Ask a question about this product
Printable version

Share

Options

Our Price:

$79.99
Quantity (20)

Details

Availability 20 in stock
Weight 0.30 lbs
SKU BBR-BLS-A208+
Manufacturer Blue Bird

BLS-A208+ MINI DIGITAL, HIGH TORQUE, HIGH SPEED, PREMIUM BRUSHLESS SERVO  (9.5kg/132.0oz 0.04 sec @8.4V)

Application
1/12 EP Car, EP Aircraft, Helicopter 250/450 Class CCPM.



Specifications
Torque At 6.0V 7.7 kg-cm / 107.0 oz-in
Torque At 7.4V 8.6 kg-cm / 119.5 oz-in
Torque At 8.4V 9.5 kg-cm / 132.0 oz-in
Speed At 6.0V 0.06 sec / 60°
Speed At 7.4V 0.05 sec / 60°
Speed At 8.4V 0.04 sec / 60°



Protection Mechanism
Soft Start Protection Soft start to a neutral position.
Locked Rotor Protection Stall in 5 sec, output torque goes down.
Lose Control Protection When losing the transmitter signal, that servo will be back to the neutral position immediately and lock.



Power Supply
Operating Voltage Range 4.5V ~ 8.5V ( 4 ~ 6 Cell Ni-MH or 2S Li-Poly / 2S Li-Fe)
Operating Temperature Range -10°C ~ +60°C ( +14°F ~ +140°F )



Control Specification
Control System 32-bit CPU Digital Calculator / AD 12-Bit Resolution (4096 Steps per turn)
Frequency：Up to 333Hz & Neutral：1500us or 1520us
Dead Band Width 0.001ms ( Default：1us)



Mechanical Specifications
Ball Bearing Dual
Gear All Metal Gears
Motor Premium Brushless Motor
Horn / Gear Spline 25 Teeth ( Same as F-Type )



Physical Specifications
Dimension (mm) 23 x 12 x 27.25 mm / 0.9 x 0.47 x 1.07 in
Weight (gram) 22.0 ± 0.5 grams / 0.78 oz
Product Picture / Dimension Sketch ​​





: *
: *
: *
