Paraboard Parallel Charging Board for Lipo /EC5+Deans Connector

This Paraboard lets you charge and balance up to six lipo batteries at once! This board features Traxxas connectors for your batteries' main leads and JST-XH balance plugs ranging from 2S to 6S. They plug right into most popular models of 6S lipo balancing chargers that have 7-pin balance ports with 2.5mm pin spacing.

To get the most out of your Paraboard, pick up one of our GT-400 chargers. It provides 400W of total charging power and charge rates of up to 20 amps! This paraboard has a maximum charge rate of 30 amps.

Battery packs must be of the same cell count (only charge 2S with 2S, 3S with 3S, etc.) and battery voltages must be within 0.1V per cell (0.1V for 1S, 0.2V for 2S, etc.) of all other batteries connected to the Paraboard at the same time. Use a Cell Spy or similar voltage tester to check the voltage of each cell before connecting to the Paraboard.

HiTec DB778WP, Ultra-Torque, Brushless, Low Profile, HV Waterproof Servo 20.4kg/283.6oz [email protected]

With ultra-efficient Neu brushless motors, titanium gear trains, low current consumption and constant output power, the HSB-93XX series of servos is the perfect match for the most discriminating pilots and racers. The HSB-9360’s speed is ideal for pilots with the need for speed!

Features:

• Power Efficient Brushless Motor Controller
  Energy efficiency is a common interest for all modelers. Our HSB-9XXX Series uses the latest control circuit technology including a regenerative braking circuit which puts power back into the battery as the motor slows. This feature, combined with ultralow current draw under sustained loads, allows our brushless servos to consume 1/5 the power of most other brushless servos on the market today.
• Custom NeuMotor
  Designed by Steve Neu exclusively for our HSB-9XXX Series, these high performance, brushless motors provide longstanding durability and performance.
• Constant Torque Output:
  Thanks to our revolutionary circuit and motor designs, the HSB-9XXX Series maintain their speed in a more consistent manner, regardless of load.
• Hybrid MPD 1st Gear:
  Our unique ultra-durable Metal/Plastic/duralumin hybrid first gear prevents inadvertent electrical noise from affecting other components within your aircraft or vehicle.
• Industry-Leading Titanium Gear Train
  Hitec was the first manufacturer to utilize low wear Titanium gears in our servos and continues to be the leader in Titanium gear technology.
• 25-Tooth Standard Spline
  Our Brushless servos utilize a standard 25 tooth output spline for maximum compatibility with the large variety of aftermarket horn available on the market these days.


  Specifications:

  • Torque:
    • 236 oz/in at 6V (17.0 kg-cm)
    • 236 oz/in at 7.4V (17.0 kg-cm)

  • Speed:
    • .08 sec at 6V
    • .06 sec at 7.4V

  • Voltage: 6V - 7.4V
  • Weight: 2.40oz (68g)
  • Size: 40 x 20 x 68 mm (1.57 x 0.79 x 1.50in)

BMS-125WV+ MICRO WIDE VOLTAGE-DIGITAL, HIGH TORQUE, CORELESS SERVO (Upgraded)
