BLS-125AWB Water Proof, ULTRA MEGA TORQUE, Brushless+Servo Arm (New generation Large Scale Servo with Dual wire to connect directly to battery) 126.5kg/1757.1oz .15sec @8.4V

Contact UsCustomer Reviews
  0
  5. BLS-125AWB Water Proof, ULTRA MEGA TORQUE, Brushless+Servo Arm (New generation Large Scale Servo with Dual wire to connect directly to battery) 126.5kg/1757.1oz .15sec @8.4V

BLS-125AWB Water Proof, ULTRA MEGA TORQUE, Brushless+Servo Arm (New generation Large Scale Servo with Dual wire to connect directly to battery) 126.5kg/1757.1oz .15sec @8.4V

Ask a question about this product
Printable version

Share

Options

Our Price:

$199.99
Quantity (10)

Details

Availability 10 in stock
Weight 0.80 lbs
SKU BBR-BLS-125AWB
Manufacturer Blue Bird

Pre-order now to reserve one in the first shippment arriving late Jan 2025!

BLS-125AWB Water Proof, ULTRA MEGA TORQUE, Brushless+Servo Arm (New generation Large Scale Servo with Dual wire to connect directly to battery) 126.5kg/1757.1oz .15sec @8.4V--Blue Bird's most powerful 1/4-1/5 scale Monster Truck/Crawler/Large Boat servo at over 1750oz!!

Water Proof IP67 (Ingress Protection Rating, 6=Dust Tight, 7=Immersion up to 1Mfor 30 min)

Application / Suitable
1/4、1/5th Scale Vehicles, such as Buggy ( Off-Road ), GT ( On-road ), Monster Truck, Rock Crawler & Large Boats, etc.



Specifications
Stall Torque At 6.6V 99.5 kg-cm / 1382.1 oz-in
Stall Torque At 7.4V 111.4 kg-cm / 1547.3 oz-in
Stall Torque At 8.4V 126.5 kg-cm / 1757.1 oz-in
No-load Speed At 6.0V 0.19 sec / 60°
No-load Speed At 7.4V 0.17 sec / 60°
No-load Speed At 8.4V 0.15 sec / 60°
Stall Current At 6.0V 11.7 Amp
Stall Current At 7.4V 13.5 Amp
Stall Current At 8.4V 15.4 Amp



Protection Mechanism
Soft Start Protection Soft start back to a neutral position.
Over Voltage Protection Over 9.0V drive the protection mode, and 8.7V return to normal mode.
Low Voltage Protection Lower than 5.8V, drive the protection mode, and 6.0V return to normal mode.
Locked Rotor Protection Stall in 3 sec, output torque goes down.
Temperature Protection Overheat 85 degrees C (185 degrees F), drive the protection mode and down 75 degrees C (167 degrees F) return to normal mode.
Lose Control Protection When losing the transmitter signal, that servo will immediately be back to the neutral position and locked.



Power Supply
Operating Voltage Range 6.0V ~ 8.7V ( 2S Li-Fe / 2S Li-Poly HV )
Operating Temperature Range -20°C ~ +60°C ( -4°F ~ +140°F )



Control Specification
Control System Higher-order Algorithm of【STMicroelectronics】32-bit MCU
AD 12-bit Resolution ( 4096 Steps )
Frequency：Up to 400Hz & 1500us or 1520us
Frame Rate (Signal repeat rate) Under 1ms【Auto-adaptive with Futaba_UR/SR & Sanwa_SXR & KO_HCS Mode】
Dead Band Width 0.002ms ( Default：2us)



Mechanical Specifications
Ball Bearing Dual, Stronger Ball Bearings with 1 piece of oil seal.【NMB from Japan】
Gear Stainless Steel Output Gear With All Steel Gears
Motor High-Efficiency Brushless Motor
Outside Case Full Aluminum Alloy Case
Horn / Gear Spline 15 Teeth ( Universal Type )
Connected Cable Length 300 mm (11.81 in) [ TYU : Black w/ Gray & JST : Red w/ Black ]
Connected Housing Universal Connector [ Black ] + JST Connector [ Red ]
Ingress Protection Rating IP67 means: 6=Dust Tight / 7=Immersion up to 1 Meter depth of 30 minutes



Physical Specifications
Dimension (mm) 65.8 x 30 x 56.5 mm / 2.59 x 1.18 x 2.22 in
Weight (gram) 229.0 ± 1 grams / 8.08 oz W/O Cable
Product Picture / Dimension Sketch


Includes Servo and Aluminum Servo Arm








: *
: *
: *

DLE 35RA Engine

DLE 35RA Engine

+ Free Shipping (Continental US only!) If international customer, please contact us for shipping quote. You will be charged separately for shipping.
+ Free 2 Year warranty





Description:
High performance in a compact package!

The DLE-35RA features a rear exhaust for the perfect tuned pipe setup. It also includes a newly designed piston with re-engineered skirt for less piston weight - resulting in such advantages as awesome throttle response, more power and longer engine life. Producing 400 more rpm than the DLE30, the DLE-35RA comes with engine standoffs, electronic ignition, spark plug and muffler.


Download DLE 35RA Mounting Template
Download DLE 35RA Manual Coming Soon


Specifications:

  • Displacement: 34.9 cc (2.13 cu in)
  • Bore: 1.5 in (38.5 mm)
  • Stroke: 1.17 in (35RA mm)
  • Weight: 2.6 lb (42oz)
  • RPM Range: 1,600-8,500
  • Output: 4.1 hp @ 8,500 rpm
  • Requires: unleaded gasoline, oil, ignition battery & propeller
  • Includes: muffler, spark plug, gasket, bolts, machined aluminum standoffs, throttle arm extension
  • Suggested Propellers: 18x6, 18x8, 19x6, 19x8, 20x8, 20x6
  • Suggested Break-in Prop: 18x6
  • Ignition Battery: 4.8-6.0V NiCd or NiMH, 6.6V LiFe or 7.4V LiPo pack (LiPo use requires voltage regulator.)
  • Compression Ratio: 7.6:1
  • Gas/Oil Mix: Break in with Lawn Boy(or similar non synthetic oil) at 32:1 Ratio per gallon / Use RedLine oil at 50:1 for long term use after break in.
  • Replacement Spark Plug: NGK CM6 (DLEG5510) or equivalent
  • Weight Breakdown: Engine: 32.1 oz (910 g); Muffler: 2.6 oz (60 g); Ignition: 5.2 oz (120g)
  • Recommended Propeller: Redwing RC 3d Props - type 19x6 19x8 20x6 20x8 Propeller





RedwingRC Pre-Run
DLE 35ra DLE55






DLE-35 RA

$379.00

DLE 55cc Engine

DLE 55cc Engine

+ Free Shipping (Continental US only!) If international customer, please contact us at [email protected] for shipping quote. You will be charged separately for shipping.

Description:
The DLE 55 is a tried and true engine in the 50cc class size. It is the best bang for the buck, and offers great reliability, power and weight ratio. Comes with all high quality components, includes all hardware (standoffs, ignition, muffler, spark plug, etc). The DLE 55cc is a perfect choice for our 50cc class airframes

Download DLE 55cc Mounting Template
Download DLE 55cc Manual

Specifications:

  • Displacement: 55.6 cc (3.392 cu in)Manifold: 4-petal, V-type, reed-valve, bottom induction
  • Bore: 1.77 in (45 mm)
  • Stroke: 1.38 X in (35 mm)
  • Weight: 3.6 lb (1.65 g)
  • RPM Range: 1,350-8,500
  • Output: 5.5 hp @ 7,500 rpm
  • Requires: unleaded gasoline, oil, ignition battery & propeller
  • Includes: electronic ignition, muffler, spark plug, gasket, bolts, machined aluminum standoffs, throttle arm extension & mounting template
  • Suggested Propellers: 23x8, 24x8
  • Ignition Battery: 4.8-6.0V NiCd or NiMH, 6.6V LiFe or 7.4V LiPo pack (LiPo use requires voltage regulator.)
  • Compression Ratio: 7.6:1
  • Gas/Oil Mix: Break in with Lawn Boy(or similar non synthetic oil) at 32:1 Ratio per gallon / Use RedLine oil at 50:1 for long term use after break in.
  • Replacement Spark Plug: NGK CM6 (DLEG5510) or equivalent
  • Weights (Individual): Engine: 47.6 oz (1,350 g); Exhaust: 3.5 oz (100 g); Ignition: 4.2 oz (120 g)
  • Recommended Propeller: Redwing 23x8, 24X8. 23x8 is a nice mix of 3d and sport. The 24x8 is more 3d

Features:







  • Two crankshaft bearings-simple design for lighter weight
  • Aluminum alloy crankcase
  • Four petal V-type reed valve bottom induction system
  • Walbro carburetor
  • Fully automatic electronic ignition
  • Two year limited warranty through Hobby Services beginning at date of purchase
  • INCLUDES: Engine, spark plug, standoffs, ignition, muffler, instruction manual

DLE-55

$399.99

DLE 55RA Engine

DLE 55RA Engine

+ Free Shipping (Continental US only!) If international customer, please contact us for shipping quote. You will be charged separately for shipping.
+ Free 2 Year warranty







Description:
More power! DLE takes 50cc performance to a new level with the rear exhaust DLE-55RA. Everything about this engine screams performance, from the piston skirt - designed to be lightweight for quick throttle response and tons of power - to the rear exhaust that lets you easily install a tuned pipe in your aircraft. The 55RA provides 100 more rpm than the standard DLE-55. It includes engines standoffs, electronic ignition, spark plug and Pitts style muffler.


To pick out your RedwingRC Props Click here.


Download DLE 55RA Mounting Template
Download DLE 55RA Manual Coming Soon



Specifications:

  • Displacement: 55.6 cc (3.392 cu in)
  • Bore: 1.77 in (45 mm)
  • Stroke: 1.38 X in (35 mm)
  • Weight: 3.6 lb (1.65 g)
  • Output: 5.5 hp @ 8,500 rpm
  • Requires: unleaded gasoline, oil, ignition battery & propeller
  • Includes: electronic ignition, muffler, spark plug, gasket, bolts, machined aluminum standoffs, throttle arm extension & mounting template
  • Suggested Propellers: 23x8, 24x8
  • Ignition Battery: 4.8-6.0V NiCd or NiMH, 6.6V LiFe or 7.4V LiPo pack (LiPo use requires voltage regulator.)
  • Compression Ratio: 7.6:1
  • Gas/Oil Mix: Break in with Lawn Boy(or similar non synthetic oil) at 32:1 Ratio per gallon / Use RedLine oil at 50:1 for long term use after break in.
  • Replacement Spark Plug: NGK CM6 (DLEG55RA10) or equivalent
  • Weights (Individual): Engine: 47 oz (1,350 g); Exhaust: 3.1 oz (100 g); Ignition: 5.1oz (120 g)
  • Recommended Propeller: Redwing 23x8, 24X8. 23x8 is a nice mix of 3d and sport. The 24x8 is more 3d








Features:







  • Two crankshaft bearings-simple design for lighter weight
  • Aluminum alloy crankcase
  • Four petal V-type reed valve bottom induction system
  • Walbro carburetor
  • Fully automatic electronic ignition
  • Two year limited warranty
  • INCLUDES: Engine, spark plug, standoffs, ignition, muffler, instruction manual




RedwingRC Pre-Run
DLE 35ra DLE55



DLE-55 RA

$449.99
